Angle Fitting DFL
The application-oriented connection of ATL profiles to built up racks.
DFL.80
DFL.100
| File Name | Subject | Link |
|---|---|---|
| DFL.80 | Technic Drawing | |
| DFL.80 | Autocad | |
| DFL.80 | Solid-3D | |
| DFL.80 | IGS-3D | |
| DFL.100 | Technic Drawing | |
| DFL.100 | Autocad | |
| DFL.100 | Solid-3D | |
| DFL.100 | IGS-3D | |
| DFL.100.4 | Technic Drawing | |
| DFL.100.4 | Autocad | |
| DFL.100.4 | Solid-3D | |
| DFL.100.4 | IGS-3D |
Insert the DFL corner fitting into the ATL profile in the horizontal direction to be connected and align the holes.
Fix it to the profile(s) with a self-forming MD screw. The screw should be tightened and threaded after the flange touches the panel.
Material : Steel S235JR (material no. 1.0038) acc. to DIN EN 10025-2
Galvanisation : Hot-dip galvanised, min. 75 μm, acc. to DIN EN ISO 1461
